Material:
Pump housing: PP+35%GF
Filter basket: PP
Shaft: SS304
Bearing: NSK
Mechanical seal: Carbon+ Resin-Ceramics (Carbon, Ceramics, SS304, NBR)
Impeller: Noryl+30% Fiberglass
Diffuser and pump base: PP+35% Fiberglass
Features:
The inlet or outlet of the pump with an external thread, which can connect with metric or imperial pipes.
The pump has excellent performance and reliable quality, which can bear 25000 times of impact test.
Low noise: 0.75HP can lower than 65 dB.
Liquid temperature: 5-50ºC(41~122ºF)
Ambient temperature: up to 45ºC(113ºF)
Maximum working pressure: 2.5bar
IPX5 waterproof standard
Class I protection against electric shock.
Thermal protection included.
Motor: 3000 r.p.m
Single phase: 220V/50Hz
220V/60Hz, 380V/50Hz are available on request
| Model | Q-max(m³/h) | H-max(m) | Horsepower(HP) | Rated Power(kW) | Phase | Voltage(V) | Connection size |
| WL-HLLF075M | 14.8 | 11.1 | 0.75 | 0.55 | 1 | 220 | 1.5″50mm |
| WL-HLLF100M | 17.4 | 14.1 | 1 | 0.75 | 1 | 220 | 1.5″50mm |
| WL-HLLF150M | 22.1 | 15.1 | 1.5 | 1.1 | 1 | 220 | 1.5″50mm |
| WL-HLLF200M | 30.2 | 16.4 | 2 | 1.5 | 1 | 220 | 2″63mm |
| WL-HLLF300M | 36 | 18.2 | 3 | 2.2 | 1 | 220 | 2″63mm |
| WL-HLLF100T | 15.8 | 13.9 | 1 | 0.75 | 3 | 380 | 1.5″50mm |
| WL-HLLF150T | 22.7 | 15.2 | 1.5 | 1.1 | 3 | 380 | 1.5″50mm |
| WL-HLLF200T | 33.1 | 16.9 | 2 | 1.5 | 3 | 380 | 2″63mm |
| WL-HLLF300T | 39.8 | 18.2 | 3 | 2.2 | 3 | 380 | 2″63mm |
